Product Advantage
Feature:
1.Superior Weatherproof Performance
Creates permanent impermeable barriers that effectively withstand prolonged water immersion and extreme weather conditions.
2.Exceptional UV & Aging Resistance
Maintains elasticity and adhesion integrity after long-term exposure to direct sunlight and harsh environmental elements.
3.Robust Aluminum Substrate Bonding
Develops powerful, durable adhesion to aluminum profiles and other metal surfaces used in building frameworks.
4.Broad Construction Material Adaptation
Demonstrates excellent compatibility with diverse building substrates including granite, coated metals, and anodized surfaces.
Technical Parameters
| Properties | Test Method | Unit | Result |
| Extrusion rate | GB/T 13477-2002 | ml/min | 619 |
| Operating temperature range | GB/T 13477-2002 | ℃ | 5 – 40℃ |
| Tack-free time | GB/T 13477-2002 | H | |
| Durometer hardness, Shore A | GB/T 13477-2002 | Shore A | 0.7 |
| Tensile Strength at 25% | GB/T 13477-2002 | Mpa | |
| Tensile Strength at Ultimate Enlongation | GB/T 13477-2002 | Mpa | 40 |
| Elongation at breake | GB/T 13477-2002 | % | 0.14 |
| sag/slump | GB/T 13477-2002 | mm | 1.21 |
| Movement Capability | GB/T 13477-2002 | 370 | |
| Tear-off strength (average) (21 days, 23℃, humidity 50%) | GB/T 13477-2002 | Mpa | 0 |
Product Uses
Applications:
1.Building Expansion Joint Sealing
Waterproofing movement joints in concrete structures and metal panel interfaces.
2.Architectural Metal Panel Installation
Seaming and weatherproofing aluminum composite panels and metal cladding systems.
3.Skylight and Glazed Roof Assembly
Creating durable weather seals in overhead glazing systems and structural glass roofs.
4.Industrial Facility Waterproofing
Sealing building envelopes in demanding environments including airports and sports arenas.
Product Operate Guide
Step 1: Make sure compatibility and adhesion between sealants and adhesive material before using.
Step 2: The sealant displays excellent adhesive effect in the clean environment with temperature of 4℃-40℃and Relative Humidity(RH)of40%-80%.
Step 3:Surface cleaning for bond substrates, clean up the dirt, grease and other contaminants, then affixedtemporary protective tape.
Step 4: According to the size you want, cut out sealant mouth.
Diameter of Gun nozzle should be smaller than the thickness ofthe sealant injection place, it makesnozzle can stretch into the 1/2 depth of the sealant injection place. Start to inject sealant whensubstrate surface is completely dry, Extrusion and injection of sealant shall be continuous ,whichmakes sure the extrusion of sealant is continuous and uniform cylinder, the move the gun slowly anduniformly, make sure the substrate interface is full of silicone sealant. Quick move is not allowed forthe gun, it will cases bubbles or holes.
Step 5: Decoration should be carried out when the injection is finished, and remove temporary protective tape.
1.Surface Cleaning
2.Affixed Tape
3.Sealant Mouth Cutting
4.Injection
5.Surface Fixing
6.Tape Remove
7.Finish
