Product Advantage
Features
1.Low-Odor, User-Friendly Application
It ensures a more comfortable and healthier workspace for installers.
2.Superior Resistance to Weathering, UV Rays, and Ozone
This preserves its integrity and appearance for extended periods outdoors.
3.Strong Adhesion to Most Common Building Substrates
It forms a powerful, permanent bond directly onto glass, metal, and painted wood.
4.Excellent Compatibility with Other Neutral Cure Sealants
This allows for reliable repairs or seamless jointing with existing materials
Technical Parameters
Test Items | Technical Indicators GB/T14683-2017 | Test Results | Remarks | ||
Appearance | Appearance:Fine uniform paste, no bubbles,no caking.No gel, no crust,no undispersed precipitates | Appearance:Fine uniform paste, no bubbles,no caking.No gel, no crust,no undispersed precipitates |
Qualified | ||
| ≥80 | 360/min | Qualified | ||
Surface Dry Time/h | ≤3 | 0.6 | Qualified | ||
Elastic recovery rate | ≥80 | 96 | Qualified | ||
Mass loss rate | ≤8 | 6.8 | Qualified | ||
Sag | Vertical Placement/mm | ≤3 | 0 | Qualified | |
Horizontal Placement | Not deformed | Not deformed | Qualified | ||
23℃ Tensile Modulus | Tensile Strength/MPa | ＞0.4 | 0.89 | Qualified | |
Destruction Area% | ≤5 | 0 | Qualified | ||
Constant elongation bonding |
Bond failure area % |
≤5 |
0 |
合格 | |
Adhesion after ultraviolet radiation |
Bond failure area % |
≤5 |
0 |
合格 | |
Constant elongation after immersion in water |
Bond failure area % |
≤5 |
0 |
合格 | |
Conclusion | The batch of products detected by the judge: （ ﹀ ）Qualified （ ）Unqualified | ||||
Product Uses
Application:
Mainly used for weatherproof caulking and sealing of glass curtain walls, aluminum plates, and stone materials.
Used for small door frame glass curtain wall structures.
Suitable for caulking various metal aluminum plate curtain walls and sealing of most materials.
Product Operate Guide
Step 1: Make sure compatibility and adhesion between sealants and adhesive material before using.
Step 2: The sealant displays excellent adhesive effect in the clean environment with temperature of 4℃-40℃and Relative Humidity(RH)of40%-80%.
Step 3:Surface cleaning for bond substrates, clean up the dirt, grease and other contaminants, then affixedtemporary protective tape.
Step 4: According to the size you want, cut out sealant mouth.
Diameter of Gun nozzle should be smaller than the thickness ofthe sealant injection place, it makesnozzle can stretch into the 1/2 depth of the sealant injection place. Start to inject sealant whensubstrate surface is completely dry, Extrusion and injection of sealant shall be continuous ,whichmakes sure the extrusion of sealant is continuous and uniform cylinder, the move the gun slowly anduniformly, make sure the substrate interface is full of silicone sealant. Quick move is not allowed forthe gun, it will cases bubbles or holes.
Step 5: Decoration should be carried out when the injection is finished, and remove temporary protective tape.
1.Surface Cleaning
2.Affixed Tape
3.Sealant Mouth Cutting
4.Injection
5.Surface Fixing
6.Tape Remove
7.Finish
