Product Advantage
Feature:
Advanced Acetic-Curing System
Rapid surface curing through acetoxy reaction ensures immediate water resistance
Optical Clarity Retention
Maintains consistent translucent properties without yellowing or clouding over time
Structural Adhesive Caulking
High-strength bonding capacity suitable for heavy glass panel fixation
Broad-Spectrum Substrate Compatibility
Reliable adhesion to multiple construction substrates including metals and composites
Technical Parameters
Silicone Sealant Item | JY868 | Batch No. | 2021.01.10 | Sampling Date | 2021.3.10 | Temperature | 23℃ | ||
| Random Sampling | Shifts | / | Detection Date | 2021.4.10 | Humidity | 50% | ||
Test Items | Technical Indicators GB14683-2003 | Test Results | Remarks | ||||||
Appearance | Appearance:Fine uniform paste, no bubbles,no caking.No gel, no crust,no undispersed precipitates | Appearance:Fine uniform paste, no bubbles,no caking.No gel, no crust,no undispersed precipitates | Qualified | ||||||
Extrusion(ml/min)s | ≥80 | 450/min | Qualified | ||||||
Curing Speed(mm/24h) | / | 10 | Qualified | ||||||
Surface Dry Time/h | ≤3 | 0.1 | Qualified | ||||||
Hardness | 20-60 | 28 | Qualified | ||||||
Attrition rate(%) | / | 2.9 | Qualified | ||||||
Elongation At Break | / | 260% | Qualified | ||||||
Sag | Vertical Placement/mm | ≤3 | 0 | Qualified | |||||
Horizontal Placement | Not deformed | Not deformed | Qualified | ||||||
23℃ Tensile Modulus | Tensile Strength/MPa | ＞0.4 | 0.7 | Qualified | |||||
Destruction Area% | ≤5 | 0 | Qualified | ||||||
Stretching Adhesion | Bonding Destruction Area% | No damage | No damage | Qualified | |||||
Conclusion | The batch of products detected by the judge: （ ﹀ ）Qualified （ ）Unqualified | ||||||||
Product Uses
Application:
Moisture-curing silicone sealant for building waterproofing.
Big panel glass seal and skylights, canopies and general glazing.
It is used for glass and anti-water seals, suitable for non-porous substrates such as glass, glazed ceramic tiles. For indoor and outdoor use.
Product Operate Guide
Step 1: Make sure compatibility and adhesion between sealants and adhesive material before using.
Step 2: The sealant displays excellent adhesive effect in the clean environment with temperature of 4℃-40℃and Relative Humidity(RH)of40%-80%.
Step 3:Surface cleaning for bond substrates, clean up the dirt, grease and other contaminants, then affixedtemporary protective tape.
Step 4: According to the size you want, cut out sealant mouth.
Diameter of Gun nozzle should be smaller than the thickness ofthe sealant injection place, it makesnozzle can stretch into the 1/2 depth of the sealant injection place. Start to inject sealant whensubstrate surface is completely dry, Extrusion and injection of sealant shall be continuous ,whichmakes sure the extrusion of sealant is continuous and uniform cylinder, the move the gun slowly anduniformly, make sure the substrate interface is full of silicone sealant. Quick move is not allowed forthe gun, it will cases bubbles or holes.
Step 5: Decoration should be carried out when the injection is finished, and remove temporary protective tape.
1.Surface Cleaning
2.Affixed Tape
3.Sealant Mouth Cutting
4.Injection
5.Surface Fixing
6.Tape Remove
7.Finish
